Modelling Distributed Control Systems Using IEC 61499: Applying Function Blocks to Distributed Systems
by Robert Lewis
The Institution of Engineering and Technology, 2001
Cloth: 978-0-85296-796-6 | eISBN: 978-1-84919-036-7

ABOUT THIS BOOK | TOC
ABOUT THIS BOOK
New technologies and standards are emerging which will have a dramatic effect on the design and implementation of future industrial control systems. PLCs and PC-based soft controllers are beginning to use software components, such as object-oriented technology, to bring together the hitherto different worlds of factory automation and business systems. New tools and techniques are needed to design and model these systems, such as UML and modern fieldbus technology. The new IEC 61499 standard has been developed specifically to model distributed control systems, defining concepts and models so that software in the form of function blocks can be interconnected to define the behavior of a distributed control system.



Tools based on IEC 61499 are likely to emerge soon to model, validate and simulate the behaviour of complex networks of function blocks and it is expected that this standard will become key to complex distributed systems.
TABLE OF CONTENTS
    1: Introduction

    2: IEC 61499 models and concepts

    3: Defining function block and subapplication types

    4: Service interface function blocks

    5: Event function blocks

    6: Industrial application examples

    7: Future development

    Bibliography

    Appendix A: Common elements

    Appendix B: Overview of XML

    Appendix C: Frequently asked questions (IEC 61499 FAQs)

    Appendix D: PID function block example

    Index
